Rubber Chevron Conveyor Belt

APPLICATION

Patterned conveyor belt is an inclination conveyor belt composed of Patterned work surface, flat non working surface and core. It is suitable for conveying powder, granular, small pieces materials with the inclination of 0 ~ 40 ° to prevent the material from falling. We often apply it in:

conveying bulk material in stone crushing plant,

waste recycling plant,

sand and gravel aggregate manufacturing plant,

thermal power station,

concrete mixer plant,

mine mining plant,

metallurgy plant,

port / terminals/ dockside, etc

FEATURES

1. There is no joint in belt carcass

2. Long service life

3. Cleats and top cover rubber are vulcanized integrally

3. Cleat pattern, angle and pitch are designed elaborately

4. There are open type and closed type, suitable for bulk or bagged materials such as powder and granule with incline less than 45°.

Type Cleat Size (mm) Belt Width (mm)

CV, full width Cleat Height=5; 10

Cleat Width= full width

Cleat Pitch=100 300-1200

CV, closed Cleat Height=15

Cleat Width=300; 450

Cleat Pitch=250; 300 400-1200

CV, open Cleat Height=15

Cleat Width=385; 600; 750

Cleat Pitch=250 450-1200

CP, open Cleat Height=17

Cleat Width=300; 440; 550; 630; 750; 950

Cleat Pitch=330 400-1400

CP, open & closed Cleat Height=25

Cleat Width=450; 550; 750

Cleat Pitch=330 500-1200

CP, open Cleat Height=32

Cleat Width=580; 630; 750

Cleat Pitch=330 700-1400

U, closed Cleat Height=15; 32

Cleat Width=550; 700

Cleat Pitch=350; 400 650-1200

Multi-V, full width Cleat Height=6

Cleat Width= full belt width

Cleat Pitch= 76 500-2000
